Description
Laser cut EMDF 14" curve T-Trak Diorama module. Easy assmbly with only tape and glue.
Holes in the top match up to Katos curved track 20120 and 20110 (Not included) for a precise fit.
45° corner consists of a module 14.292"x14.292"x 2.75 365 mm long on each side. Track consists of two pieces of Kato 20-120 radius 315-45 and two pieces of Kato 20-110 radius 282-45. These radis permit a double row of modules on a single folding table.
Included in this kit is
1 x front
2 x sides
1 x back
1 x top
4 x leg corners
4 x Set screws
4 x feet for set screws
Not included
You will need
Wood Glue, or glue of your choice
Blue Tape or tape of your choice.
1/8” hex key,
6mm hex key,
2 x 20-110 2 x 20-120 Kato track
Details
Store Location: |
P# 250 / Aisle 12C #floor |
Scale: |
N Scale |
